PWBs ＞ Description for PWB (OPTION)
[CONFIDENTIAL]
3 FEED B O DC0V/24V Paper feed motor drive output
4 FEED BN O DC0V/24V Paper feed motor drive output
YC4 1 MOTOR2 O DC0V/24V PF lift motor drive output
2 MOTOR1 O DC0V/24V PF lift motor drive output
YC5 1 UPLED O DC3.3V Power source
2 GND O - Ground
3 UPLIMIT I DC0V/3.3V UPLIMIT signal
YC6 1 GND/3.3V O - Power output
2 COVER I DC0V/3.3V COVER signal
YC7 1 DOWNLED O DC3.3V Power source
2 GND O - Ground
3 DOWNLIMIT I DC0V/3.3V DWNLIMIT signal
Connector Pins Signal I/O Voltage Description
To Next Page
