Table 3: M1 Quick Setup
Index Parameter Min Max Unit Default ID Description
1.2
Application 0 5 0 212
0 = Standard
1 = Local/Remote
2 = Multi-Step Speed
3 = PID Control
4 = Multi-Purpose
5 = Motor
Potentiometer
1.3
Minimum Frequency
Reference
0.00 P1.4 Hz 0.0 101
The minimum
frequency reference
that is acceptable.
1.4
Maximum Frequency
Reference
P1.3 320.0 Hz
50.0 /
60.0
102
The maximum
frequency reference
that is acceptable.
1.5 Acceleration Time 1 0.1 300.0 s 5.0 103
Gives the quantity of
time that is necessary
for the output
frequency to increase
from zero frequency to
the maximum
frequency.
1.6 Deceleration Time 1 0.1 300.0 s 5.0 104
Gives the quantity of
time that is necessary
for the output
frequency to decrease
from the maximum
frequency to zero
frequency.
1.7 Motor Current Limit I
H
*0.1 I
S
A Varies 107
The maximum motor
current from the AC
drive.
1.8 Motor Type 0 1 0 650
0 = Induction Motor
1 = Permanent Magnet
Motor
1.9
Motor Nominal
Voltage
Varies Varies V Varies 110
Find this value U
n
on
the rating plate of the
motor.
NOTE!
Find out if the motor
connection is Delta or
Star.
QUICK STARTUP GUIDE VACON · 17
