Table 79: Timer 1
Index Parameter Min Max Unit Default ID Description
P3.12.6.1 Duration 0 72000 s 0 1489
The time that the timer
runs when it is
activated by DI.
P3.12.6.2 Timer 1
DigINSlot
0.1
447
The rising edge starts
Timer 1 that is
programmed in Group
3.12.
P3.12.6.3 Assign to Channel 1490
The selection of the
time channel.
A checkbox
selection
B0 = Time channel 1
B1 = Time channel 2
B2 = Time channel 3
Table 80: Timer 2
Index Parameter Min Max Unit Default ID Description
P3.12.7.1 Duration 0 72000 s 0 1491 See Timer 1.
P3.12.7.2 Timer 2
DigINSlot
0.1
448
See Timer 1.
P3.12.7.3 Assign to Channel 1492 See Timer 1.
Table 81: Timer 3
Index Parameter Min Max Unit Default ID Description
P3.12.8.1 Duration 0 72000 s 0 1493 See Timer 1.
P3.12.8.2 Timer 3
DigINSlot
0.1
449
See Timer 1.
P3.12.8.3 Assign to Channel 1494 See Timer 1.
PARAMETERS MENU VACON · 171
