Vacon 100 Applications Manual

NOTE!
The command Change direction is available in the menu only if the current control
place is Local.
1 Anywhere in the menu structure, push the FUNCT
button.
2 To make a selection of the Change direction, push
the arrow buttons Up and Down. Push the OK
button.
3 Make a selection of a new rotation direction. The
current rotation direction blinks. Push the OK
button. The rotation direction changes immediately,
and the arrow indication in the status field of the
display changes.
THE QUICK EDIT FUNCTION
With the Quick edit function, you can have a quick access to a parameter by typing the ID
number of the parameter.
1 Anywhere in the menu structure, push the FUNCT
button.
2 Push the arrow buttons Up and Down to make a
selection of Quick Edit and accept with the OK
button.
3 Write the ID number of a parameter or monitoring
value. Push OK. The display shows the parameter
value in the edit mode and the monitoring value in
the monitoring mode.
VACON · 92 USER INTERFACES
3
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205

Vacon 100 Specifications

General

Product type	AC Drive
Enclosure class	IP20
EMC filter	Built-in
Power	0.25 kW - 5.5 kW
Cooling method	Fan
Braking chopper	Optional
