HEAD ASSEMBLY : FIXED COLOR WHEEL ASSEMBLIES
02.9686.0010 0 85
3
Fixed Color Wheel Assemblies
21.9686.0484 Rev G Wheel #1
21.9686.0480 Rev G Wheel #2
Refer to Figure 3-21
No. Item Qty. UM. Description
1 10.9686.0487 1 EA WHEEL, FIXED COLOR 1 (#1)
-10.9686.0481 1 EA WHEEL, FIXED COLOR 2 (#2)
2 10.9686.0482 1 EA SPACER PLATE, FIXED COLOR
3 10.9686.0483 1 EA SPRING PLATE, FIXED COLOR
4 21.9686.0419 1 EA TIMING PULLEY WITH BEARINGS
5 41.9686.0490 1 EA COLOR FILTER, RED (#1)
-41.9686.0495 1 EA COLOR FILTER, BLUE (#2)
6 41.9686.0491 1 EA COLOR FILTER, YELLOW (#1)
-41.9686.0496 1 EA COLOR FILTER, AMBER (#2)
7 41.9686.0492 1 EA COLOR FILTER, MAGENTA (#1)
-41.9686.0497 1 EA COLOR FILTER, DARK FUSHIA (#2)
8 41.9686.0493 1 EA COLOR FILTER, KELLY GREEN (#1)
-41.9686.0498 1 EA COLOR FILTER, ORANGE (#2)
9 41.9686.0494 1 EA COLOR FILTER, CONGO BLUE (#1)
-41.9686.0499 1 EA COLOR FILTER, GREEN (#2)
10 53.6598.0312 4 EA SCREW, 4-40 X 5/16 " PFB
