VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
140 02.9686.0010 0
Yoke Fan Cable Assembly
25.9678.0758 Rev A
Refer to Figure 3-65
Figure 3-65: Yoke Fan Cable Assembly
No. Item Qty. UM. Description
1 52.6396.3102 1 EA RECEPT, 2POS MTA100 W/POL TAB BLUE CLSD END
2 52.6423.0003 1 EA HOUSING, 3POS MT RECEPT, 2MM CT 28-26 AWG
3 73.5126.0002 .5 FT WIRE, 26AWG 2COND 300V 80C <BLK-RED> UL1061, 19STRND
1
2
3
