Pan Motor Assembly
21.9686.0864 Rev C
Refer to Figure 3-45
No. Item Qty. UM. Description
1 10.9686.0865 1 EA PLATE, PAN MOTOR MOUNT
2 21.9686.0828 1 EA ASSY, DRIVE PULLEY, PAN
- 10.9686.8720 1 EA CODEWHEEL, 120 COUNT LARGE ID
- 10.9686.0749 1 EA TIMING PULLEY, 2MM GT 15 TOOTH
- 53.5560.0250 1 EA SCREW, 8-32 X 1/4" SET CONE POINT
3 24.9678.9729 1 EA PCB ASSY, VL2203 PAN/TILT ENCODER
4 44.9678.0680 1 EA MOTOR, 3 PHASE SIZE 23 HIGH TORQUE
5 53.2200.0008 4 EA NUT, 8-32 KEPS SS
6 53.6546.0001 4 EA SCREW, 8-32 X 5/8" PPB
7 53.6682.0002 4 EA SCREW, 4-40 X 1/4"LG PPZ SEMS-EXT
8 10.9686.0840 2 EA STANDOFF, 1/4" 4-40/8-32 0.791" LG AL
9 10.9686.0457.01 2 EA SPACER, COLOR, .322 LG
10 54.1259.0009 6 EA BEARING, 1/4" ID, 1/2" OD EXT. INNER RACE
11 53.6575.0009 2 EA SCREW, 8-32 X 3/8" LG PPZ SEMS
12 10.9686.0841 1 EA ADAPTOR PLATE, PAN SENSOR PCB
