Vari Lite VL3500 - AC Input Splitter Cable Assembly

VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
148 02.9686.0010 0
AC Input Splitter Cable Assembly
25.9678.0812 Rev E
Refer to Figure 3-73
No. Item Qty. UM. Description
1 52.6231.0001 1 EA PLUG HOUSING, MNLOK PLUG 3 POS
2 52.8231.0005 1 EA TERM, RING #6 BLUE 16-14 AWG REEL PIDG
3 52.8231.0008 2 EA TERM, SPADE #6 RED 22-16 AWG INSERT
4 52.8392.0001 2 EA RECP, FASTON .187" X 0.32" 16-14 AWG FLAG DBL CRP
5 52.8270.0001 2 EA CONTACT PIN, 20-14 AWG MNLOK (REEL)
6 52.8314.0001 1 EA PIN, GND 20-14 AWG MNLOK .060"- .130"INS DIA
7 55.2186.0001 3 EA CABLE TIE, .10" WD, 4.00" LG, SMALL
8 55.6699.0003 1.50 FT SLEEVING, 1/2" NOM. DIA. POLY EXP BRAIDED
9 73.6016.0009 1.83 FT WIRE, 16 AWG 600V 105C PVC WHT UL1015
10 73.6016.0010 1.83 FT WIRE, 16 AWG 600V 105C PVC BLK UL1015
11 73.6016.0504 2.08 FT WIRE, 16 AWG 600V 105C PVC GRN/YEL UL1015
12 73.6018.0009 1.00 FT WIRE, 18 AWG 600V 105C PVC WHT UL1015
13 73.6018.0010 1.00 FT WIRE, 18 AWG 600V 105C PVC BLK UL1015
