VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
126 02.9686.0010 0
Ignitor to Relay Cable Assembly
25.9661.1526 Rev C
Refer to Figure 3-51.
Figure 3-51: Ignitor to Relay Cable Assembly
No. Item Qty. UM. Description
1 52.8231.0005 1 EA TERM, RING #6 BLUE 16-14 AWG (LOOSE) PIDG
2 52.8312.0001 1 EA RECP, FASTON 1/4" 18-14 AWG INSULATED VO
3 73.7101.0009 0.42
FT
WIRE, 14AWG 15KV 150C SILICONE 41/30 STRANDING
2
3
1
