VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
82 02.9686.0010 0
Color/Effect/Strobe Module
21.9686.0400 Rev G
Refer to Figure 3-20 and Figure 3-20
No. Item Qty. UM. Description
1 10.9686.0468 6 EA PULLEY, COLOR WHEEL DRIVE MOTOR, WITH FLANGES
2 10.9676.0230.02 3 EA SPACER, COLOR WHEEL .043" LG
3 10.9686.0446 1 EA MOTOR ADJUST PLATE
4 10.9686.0420 1 EA BULKHEAD, COLOR MODULE, FRONT
5 10.9686.0421 1 EA BULKHEAD, COLOR MODULE, REAR
6 10.9686.0422 2 EA SHAFT, COLOR WHEEL, FRONT
7 10.9686.0432 2 EA SHAFT, COLOR WHEEL, REAR
8 10.9686.0433 5 EA SPACER, COLOR SYSTEM HALVES
9 10.9686.0457.01 2 EA SPACER, COLOR WHEEL .322" LG
10 10.9686.0457.02 2 EA SPACER, COLOR WHEEL .125 LG
11 21.9686.0404 1 EA ASSEMBLY, STROBE SYSTEM
12 21.9686.0480 1 EA ASSY, FIXED COLOR WHEEL #2
13 21.9686.0484 1 EA ASSY, FIXED COLOR WHEEL #1
14 22.9686.0410 1 EA ASSY, COLOR WHEEL, CYAN
15 22.9686.0411 1 EA ASSY, COLOR WHEEL, YELLOW
16 22.9686.0412 1 EA ASSY, COLOR WHEEL, MAGENTA
17 22.9686.0413 1 EA ASSY, COLOR WHEEL, CTO
18 22.9686.0414 1 EA ASSY, DIMMER WHEEL
19 22.9686.0490 1 EA ASSY, APERTURE WHEEL
20 24.9686.0427 1 EA BOARD. ASMB COLOR WHEEL SENSOR, TRIPLE
21 24.9686.0428 1 EA BOARD. ASMB COLOR WHEEL SENSOR, QUAD
22 44.9663.1766 8 EA MOTOR, 17 1.24" SHAFT 11.8MH 5.5 OHM
23 54.2057.0001 8 EA BELT, TIMING MXL .188W 144 GRV URETH/KEVLAR
24 53.6609.0001 14 EA SCREW, 6-32 X 3/8" PFZ
25 53.6613.0001 16 EA SCREW, 6-32 X 1/2" PPZ
26 55.6669.0014 6 EA STANDOFF, 1/4 "HEX 6-32 5/8"
27 10.9686.0457.03 1 EA SPACER, COLOR WHEEL, .490" LG
28 10.9686.0457.04 1 EA SPACER, COLOR WHEEL, .090" LG
29 10.9686.0457.05 1 EA SPACER, COLOR WHEEL, .271" LG
30 53.6525.0188 4 EA SCREW, 6-32 X 3/16" PPZ SEMS
31 53.6558.0009 6 EA SCREW, 6-32 X 3/8"LG PPZ SEM
