Vari Lite VL3500 - Enclosure Assembly Upper Enclosure Assembly

ENCLOSURE ASSEMBLY : UPPER ENCLOSURE ASSEMBLY
02.9686.0010 0 105
3
Enclosure Assembly
Upper Enclosure Assembly
21.9686.0800 Rev H
Refer to Figure 3-36 and Figure 3-37
No. Item Qty. UM. Description
1 04.9640.0374 1 EA LABEL, P.E. GROUND
2 04.9661.1218.01 1 EA LABEL, PATENT, VL2201 & VL2400 SERIES LUM.
3 04.9686.0040 1 EA LABEL, VL3500 WASH SERIES COMPLIANCE
4 06.6032.0009 1 EA CABLE MARKER TIE
5 10.9661.1258 1 EA BRACKET, APS SIDE
6 10.9678.1876 1 EA AIR DISTRIBUTION PLENUM
7 10.9678.0820 1 EA LANYARD, PAN TUBE
8 10.9686.0839 2 EA COVER, TOP
9 10.9686.0846 2 EA HANDLE, CAST ENCLOSURE
10 10.9678.0869 1 EA BRACKET, LVS
11 10.9678.0892 1 EA BUSHING, WIRE PROTECTION PAN
12 10.9678.0886 1 EA SPACER, PAN BEARING, .235" THK
13 12.9686.1236 2 EA MACHINED, COVER FRONT
14 12.9686.1238 2 EA MACHINED, COVER SIDE
15 12.9678.0842 1 EA AIR DUCT, UPPER ENCLOSURE MOD
16 21.9686.0840.02 1 EA ASSY, COVER - VENTILATION
17 21.9678.0767 1 EA ASSY, STABILIZER
17a - 10.9678.0757 1 EA STABILIZER, 1.377DIA
17b - 10.9678.0762 1 EA BRACKET, STABLIZER
17c - 53.6610.0003 1 EA SCREW, 6-32 X 7/16" PPZ
17d - 55.6568.0075 1 EA SPRING, EXTSN .375"OD 1.00"LG .041" WIRE DIA
18 21.9686.0805 1 EA ASSY, PANEL
19 21.9686.0807 1 EA ASSY, PAN PULLEY
20 21.9686.0864 1 EA ASSY, PAN MOTOR
21 21.9678.0881 1 EA ASSY, PAN TUBE
22 22.9686.0851 1 EA ASSY, UPPER ENCLOSURE
23 23.9686.1500 1 EA ASSY, BALLAST MODULE, 1500W ARC
(INCLUDES ATTACHED FERRITE)
24 23.9686.0824 1 EA FAN ASSY, UPPER ENCLOSURE
