Vari Lite VL3500 - Yoke Assembly Yoke Assembly

YOKE ASSEMBLY : YOKE ASSEMBLY
02.9686.0010 0 91
3
Yoke Assembly
Yoke Assembly
21.9686.0700 Rev A
Refer to Figure 3-25
No. Item Qty. UM. Description
1 10.9678.0764 1 EA PLATE, TILT ENCODER MOUNT
2 10.9678.0756 1 EA IGNITOR SHIELD
3 21.9678.0765 1 EA ASSY, TILT MOTOR
4 22.9661.0609 2 EA ASSY, YOKE FAN
5 22.9686.0705 1 EA ASSY, YOKE STRUCTURE
6 23.9650.3327 1EAELEC ASSY, RELAY
7 23.9661.1253 1 EA ELEC ASSY, PAN EOT SENSOR
8 24.9661.3126 1 EA PCB ASSY, SOLID STATE IGNITOR
- 25.9661.1526 2 EA CABLE ASSY, IGNITOR TO RELAY
- 25.9678.0681 1 EA CABLE ASSY, YOKE FAN AND RELAY
- 25.9678.0758 1 EA CABLE ASSY, YOKE FAN
9 53.2019.0004 2 EA NUT, 3/8-16 X 7/32" THK HEX
10 53.2200.0006 1 EA NUT, 6-32 KEPS SS
11 53.5634.0250 8 EA SCREW, 4-40 X 1/4" PFSS BL
12 53.6539.0001 2 EA WASHER, 3/8" SPLIT LOCK
13 53.6558.0009 12 EA SCREW, 6-32 X 3/8"LG PPZ SEM
14 53.6626.0001 6 EA SCREW, 10-32 X 1/2" PPZ
15 53.6634.0003 2 EA SCREW, 3/8-16 X 1/2"LG SOC
16 55.2150.0002 1 EA STANDOFF, 1/4" HEX 6-32 1.187"L
17 55.2178.0001 1 EA CABLE ANCHOR MOUNT, #8 SCREW MOUNT
18 55.6528.0001 2 EA WASHER, #6 FLAT ZINC
19 55.6541.0002 2 EA GROMMET, 1 "ID 1 3/4"OD 1 3/
20 55.6568.0074 2 EA SPRING, CPRSN .420"OD .750"LG
21 55.6658.0004 2 EA STANDOFF, 1/4" HEX 6-32 .750"LG, F-F, AL
