HEAD ASSEMBLY : INTERNAL LENS ASSEMBLY
02.9686.0010 0 73
3
Internal Lens Assembly
21.9686.2150 Rev G
Refer to Figure 3-13
No. Item Qty. UM. Description
1 21.9686.2140 1 EA ASSEMBLY, INTERNAL LENS RAIL
2 21.9686.2144 1 EA ASSEMBLY, INTERNAL LENS SPLITTER
3 21.9686.2142 1 EA ACTUATOR ASSEMBLY
4 53.6607.0001 1 EA SCREW, 6-32 X 1/4 PPB
5 53.6513.0046 4 EA SCREW, M3 X 6 LG SOC CAP, LOW PROFILE, BLK
6 53.6513.0032 4 EA SCREW, M3 X 5 X 10MM LG, PPZ, METRIC
7 21.9686.3102 1 EA ASSEMBLY, SPLIT ZOOM BUXOM, RIGHT
8 21.9686.3101 1 EA ASSEMBLY, SPLIT ZOOM BUXOM, LEFT
9 21.9686.3105 2 EA INTERNAL LENS MOUNTING KIT
10 10.9686.2180 1 EA CROSS STRAP, BEAM SPLITTER
11 10.9686.2190 1 EA BUMPER, LENS
12 10.9686.7135 2 EA KNOB, HEX, ALUMINUM
13 10.9686.1155 1 EA CLAMP, BELT, FRONT
