HEAD ASSEMBLY : INTERNAL LENS SPLITTER ASSEMBLY
02.9686.0010 0 77
3
Internal Lens Splitter Assembly
21.9686.2144 Rev D
Refer to Figure 3-15
No. Item Qty. UM. Description
1 10.9686.2175 1 EA MOUNT, ZOOM LENS
2 10.9686.1179 2 EA HINGE ROD
3 21.9686.2160 2 EA PIVOT ASSY, INTERNAL LENS
4 10.9686.2189 1 EA EOT STOP, VARI-BRITE
5 10.9686.1156 1 EA BELT CLAMP, BACK
6 10.9686.1159 2 EA SPACER, PIVOT
7 10.9686.1176 1 EA MOTOR MOUNT 1, SPLIT LENS MOTOR
8 44.9686.0164 1 EA MOTOR, SPLIT LENS
9 53.6524.0002 4 EA SCREW, 6-32 X 5/16" PPB
10 53.6592.0250 2 EA SCREW, 4-40 X 1/4" LG PPB SEMS
11 53.6607.0001 2 EA SCREW, 6-32 X 1/4" PPB
12 54.2007.0001 2 EA RING, RETAINING EXTERNAL 1/4"
