Vari Lite VL3500 - Color Filter Replacement (Continued)

MAINTENANCE PROCEDURES : COLOR FILTER REPLACEMENT (CONTINUED)
02.9686.0010 0 25
2
Color Filter Replacement (continued)
Figure 2-5: Replacing a Color Filter
Air Duct Door
Lock Pins
1
2
3
Color Filter
Assembly With Color Wheels
(Do not remove. See detail)
CAUTION:
Do not touch filters with bare fingers.
Wear cotton gloves.
Color Wheel 1
Lock Pins
Color Filter
1
2
Color Wheel 2
