VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
130 02.9686.0010 0
Backcap Interlok to OT Switch 1 Cable Assembly
25.9686.0014 Rev A
Refer to Figure 3-55
Figure 3-55: Backcap Interlok to OT Switch 1 Cable Assembly
No. Item Qty. UM. Description
1 52.8414.0001 1 EA RECEPT, FASTON, .187 SERIES 24-20 AWG UNINSUL
2 52.8371.0001 1 EA RECEPT, FASTON, 24-20 AWG UNINSUL
3 73.7089.0000 0.33 FT WIRE. 22AWG 300V 200C TEF BLK UL1180
2
3
1
