VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
32 02.9686.0010 0
Reflector Replacement
VL Part No: 42.9686.0120
Repair Procedure
Step 1. Disconnect luminaire AC input cable from power source.
Step 2. Remove the Color/Dimmer/Strobe Assembly. See “Color/Dimmer/Strobe Assembly
Replacement” on page 28 for complete instructions.
Step 3. As shown in Figure 2-9, remove four 4-40 x 1 3/8" PPZ screws.
Step 4. Carefully remove the UV/Reflector assembly.
Step 5. Remove the springs from the reflector clamp and remove the reflector.
Step 6. Replace the reflector and UV/Reflector assembly in reverse order. Make sure the mark on
the reflector lines up with the mark on the top-left reflector support; see the illustration in
Figure 2-9.
