Vari Lite VL3500 - Zoom Motor Cable Assembly

VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
136 02.9686.0010 0
Zoom Motor Cable
25.9686.0207 Rev 0
Refer to Figure 3-61
Figure 3-61: Zoom Motor Cable
No. Item Qty. UM. Description
1 52.662.0006 1 EA HOUSING, 6 POS, 125/2A 2.00 MM PITCH
2 52.6467.0024 4 EA CONTACT, 24-30 AWG FEMALE CRIMP 2.00 MM PITCH
3 73.2326.0123 0.75 FT WIRE, 26 AWG, 4 COND, 300V 200C TEF UL1180 (BLK-BRN-RED-ORN)
1
2 (x4)
3
