VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
64 02.9686.0010 0
Backend Assembly
21.9686.0615 Rev M
Refer to Figure 3-6
No. Item Qty. UM. Description
1 10.9678.0653 1 EA LIGHT BAFFLE, EXHAUST
2 10.9686.0635 1 EA EXHAUST BULKHEAD
3 10.9686.0636 10 EA COUNTERWEIGHT, REAR
4 10.9686.0671 1 EA SEPARATION BULKHEAD
5 12.9678.0627 1 EA REAR CROSS-CASTING, MACHINED
6 10.9686.0659 1 EA INSULATOR, FAN, THIN
7 21.9678.0673 1 EA TETHER ASSY, COVERED
8 21.9686.0673 1 EA TETHER ASSY, BARE
9 21.9686.0605 1 EA ASSEMBLY, REFLECTOR MOUNT
10 22.9686.0674 1 EA ASSEMBLY, DUAL FAN DUCT
11 21.9686.0680 1 EA ASSEMBLY, HOT BOX
12 21.9686.6619 2 EA FAN ASSY, AC 80MM 36CFM
13 53.2002.0001 2 EA NUT, 6-32 KEPS ZINC PLATED
14 53.2004.0002 4 EA NUT, 8-32 KEPS ZINC PLATE
15 53.6545.0009 4 EA SCREW, 8-32 X 1.375"LG PFZ
16 53.6519.0001 2 EA SCREW, 4-40 X 5/8" PPZ
17 53.6558.0007 2 EA SCREW, 6-32 X 1/4" PPZ SEMS
18 53.6581.0001 4 EA SCREW, 4-40 X 1 3/8" PPZ
19 53.6609.0001 10 EA SCREW, 6-32 X 3/8" PFZ
20 53.6614.0003 4 EA SCREW, 6-32 X 5/8" PFZ
21 53.6617.0001 10 EA SCREW, 6-32 X 1" PPB
22 55.2125.0003 4 EA STANDOFF, 3/8"HEX 8-32 1.500"L
23 55.6706.0001 1 EA GROMMET, 9/32"ID 9/16"OD 1/4T
24 74.1099.0001 1 EA SWITCH, MINIATURE 5AMP 150DEG
25 55.6541.0008 1 EA GROMMET, 1/2"ID 7/8"OD 3/4"GRV
26 55.6506.0024 2 EA SPACER, 3/16 RND, .188 LG, .141 THRU
27 55.6528.0001 2 EA WASHER, #6 FLAT, ZINC
28 55.6538.0004 4 EA WASHER, .750" OD, .312" ID, .125 THK
29 53.6613.0001 2 EA SCREW, 6-32 X 1/2" PPZ
30 55.6677.0042 2 EA WASHER, .500" OD, .145" ID, .031" THICK
31 10.9678.1645 2 EA FAN LIGHT SHIELD
