YOKE ASSEMBLY : YOKE FAN ASSEMBLY
02.9686.0010 0 95
3
Yoke Fan Assembly
22.9661.0609 Rev C
Refer to Figure 3-28
Figure 3-28: Yoke Fan Assembly
No. Item Qty. UM. Description
1 10.9661.0646 1 EA FAN TRAY
2 40.7113.0001 1 EA FAN, +24V 80MM X 80MM X 25MM, 32 CFM
3 53.2200.0006 4 EA NUT, 6-32 KEPS SS
1
2
3 (x4)
Direction of Air Flow
To Next Page
