HEAD ASSEMBLY : STROBE SYSTEM ASSEMBLY
02.9686.0010 0 87
3
Strobe System Assembly
21.9686.0404 Rev F
Refer to Figure 3-22
No. Item Qty. UM. Description
1 10.9678.0491 4 EA BUMPER STOP, STROBE
2 10.9686.0435 1 EA STROBE BULKHEAD, COLOR ACCESS
3 22.9686.0437 1 EA REAR STROBE BLADE ASSEMBLY
4 22.9686.0438 1 EA FRONT STROBE BLADE ASSEMBLY
5 44.5029.0001 2 EA MOTOR, STEPPER 42MM X 34MM - AR6
6 53.6513.0026 8 EA SCREW, M3 X .5 X 12MM LG PP
7 53.6609.0001 4 EA SCREW, 6-32 X 3/8" LG PFZ
8 55.3303.0004 8 EA WASHER, #4 LOCK INT. TOOTH SS
9 55.3306.0006 8 EA WASHER, .375 OD .149 ID .025 THK
10 55.6659.0001 8 EA SPACER, 1/4" RND 4 THRU 3/16"
11 55.6706.0001 8 EA GROMMET, 9/32"ID 9/16"OD 1/4T
12 53.6558.0007 4 EA SCREW, 6-32 X 1/4" PPZ SEMS
13 10.9686.0440 1 EA SHIELD, STROBE MOTOR/HARNESS
14 21.9686.0404 1 EA ASSY, AIR DUCT
15 10.9686.0438 1 EA SPRING, COLOR ACCESS
16 55.2023.0002 1 EA HINGE,1.00"LG X 1.00"WD, ZINC STEEL
17 53.6558.0001 4 EA SCREW, 6-32 X 3/8" PPZ
18 10.9686.1450 1 EA REFLECTOR, STROBE BULKHEAD
To Next Page
