VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
4 02.9686.0010 0
Features
Standard Features
All VL3000 series luminaire have the following standard features:
• Three filter CYM color mixing system.
• Variable CTO color correction.
• Full field dimming system.
• Dual blade strobe system.
• Repositional pan/tilt system.
• Control by DMX512 protocol.
• Fan cooled.
• UV/IR glass.
• 1200W lamp source.
Specific Features
VL3500 Wash Luminaire
• VARI❋BRITE
TM
mode - produces a tight, intense column of light.
• Zoomable beam optics mechanism for continuous beam size control with a 10° to 50° range,
which depends on lens configuration.
• Dual five-position (plus open) fixed color wheels.
• Interchangeable lenses: Fresnel, Plano Convex Stippled, Plano Convex Clear.
• 1500W, double-ended, short arc lamp.
• Five-position aperture wheel: 52, 40, 35, 30, and 25 mm.
WARNING: Some exceptional conditions apply to the safe operation of the VL3500™ Wash
Luminaire. See “Warnings and Cautions” on page 13.
Technical Specifications
For technical specifications, refer to VL3500™ Wash Luminaire User’s Manual (02.9686.0001).
