VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
150 02.9686.0010 0
Data I/O Link Cable Assembly
25.9678.0813 Rev A
Refer to Figure 3-74
Figure 3-74: Data I/O Link Cable Assembly
No. Item Qty. UM. Description
1 52.6396.2904 1 EA RECEPT, 4 POS MTA100 W/POL TAB RED CLSD END
2 52.6396.2905 1 EA RECEPT, 5 POS MTA100 W/POL TAB RED CLSD END
3 73.5122.0259 2.17 FT CBL, 22AWG STRND 4COND PVC INSUL
2
1
3
