Vari Lite VL3500 - Hot Box Assembly

HEAD ASSEMBLY : HOT BOX ASSEMBLY
02.9686.0010 0 69
3
Hot Box Assembly
21.9686.0680 Rev D
Refer to Figure 3-10
No. Item Qty. UM. Description
1 10.9678.0043-04 1 EA LABEL PLATE, VL3500 WASH BACKCAP, BLACK
2 10.9686.0642 1 EA BACKCAP PLATE
3 10.9678.0643 1 EA LAMP ADJUST STOP
4 10.9678.0645 3 EA KNOB, LAMP ADJ MOLDED
5 10.9686.0681 1 EA HOT BOX
6 22.9686.0649 1 EA ASSEMBLY, TILT PLATE, LONG VANE
7 53.2030.0001 3 EA NUT, ACORN 10-32THD 3/8 WIDE
8 53.5508.0375 2 EA SCREW, 8-32 X 3/8" PPSS
9 53.6530.0013 8 EA RIVET, 1/8"OD .063" - .125"GL CSK HD ALUM
10 55.6546.0004 3 EA WASHER, TEFLON, .201ID X .438OD X .04 THK
11 55.2233.0003 4 EA RETAINER, PUSH-ON TYPE
12 55.2233.0006 4 EA STUD, 1/4 TURN OPR .455L STEEL
13 55.6568.0035 3 EA SPRING, CPRSN .300"OD .875"LG .035"WIRE DIA SS
14 71.2561.0002 1 EA LAMPHOLDER, SFC10-4 WITH PREFOCUS SHARX
15 25.9678.0789 1 EA CABLE ASSY, IGNITOR TO LAMP SOCKET (
NOT SHOWN)
