VL3500 Wash Luminaire Head and Yoke Components
The following illustration shows the major sub-assemblies, which are located in the luminaire head
and yoke assemblies.
Front Lens Assembly
Yoke Arm Cover
Yoke Arm
Houses lamp.
Provides knobs for lamp
Backend Assembly
adjustment.
Main Controller Board (MCB)
Luminaire control circuit board.
Head Fan Assemblies
Contains fixed color wheel,
dimmer mechanism, aperture wheel,
Color Assembly
strobe mechanism, color mixer
Head Cover
(attached by tether)
Cover
and CTO color correction.
Enclosure
Assembly
see page 7
Houses zoom lenses
and Vari*Brite
Optics Assembly
mechanism.
