COMPONENTS : EXTERNAL LUMINAIRE COMPONENTS
02.9686.0010 0 5
1
Components
External Luminaire Components
The following illustration shows the external luminaire components and controls.
CAUTION:
RISK OF EXPOSURE TO EXCESSIVE ULTRAVIOLET RADIATION. DO NOT OPERATE
WITHOUT COMPLETE LAMP ENCLOSURE IN PLACE OR WHEN LENS IS DAMAGED.
ATTENTION:
RISQUE D'INCENDIE. UTILISER UNIQUEMENT UNE LAMP A HALOGENE EN METAL DE
TYPE H, 1500 WATT, 100V ET UN SUPPORT SFc10-4.
CAUTION:
RISK OF FIRE. USE ONLY 1500 WATT, H TYPE 100V METAL HALIDE LAMP,
SFc10-4 BASE.
DISCONNECT FIXTURE
BEFORE RELAMPING
CAUTION:
HOT LAMP
LUMINAIRE MUST REMAIN
POWERED ON FOR 5 MINUTES
AFTER DOUSING LAMP.
DO NOT OPEN FOR 5 MINUTES
AFTER SWITCHING OFF.
DATA THRU
ENTERMENU
AC PWR
DATA IN
~
AC IN
Main Power
Switch
AC Input Cable
Data In
Data Thru
Product Label ID
AC Input Cable
Head Assembly
Menu Display
Used to input manual
commands, program, test,
set defaults and access
Houses Master Control
Houses color, strobe, and
beam spreader mechanisms
Yoke Assembly
internal status information.
Upper Enclosure Assembly
Houses power supply, ballast,
and display board.
X
YZ
Beam Adjustment Controls
Input Panel Components
Board (MCB).
Input Panel
Provides DMX In and Thru,
and AC Power connections.
(see detail below)
Backcap Assembly
Provides access to lamp
for replacement and
provides controls for
beam adjustment.
Front Lens Assembly
