VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
56 02.9686.0010 0
Generic Luminaire Assembly
21.9686.0010 Rev C
Refer to Figure 3-5
No. Item Qty. UM. Description
1 21.9686.0600 1 EA ASSY, HEAD STRUCTURE, VL3500 WASH
2 21.9686.0700 1 EA ASSY, YOKE
3 21.9678.0707 1 EA ASSY, DRIVEN PULLEY
3a - 10.9678.0750 1 EA TIMING PULLEY, 150 TOOTH
3b - 10.9678.0754 1 EA FLAG, CENTER OF TRAVEL, TILT
3c - 53.6530.0009 3 EA RIVET, 1/8"OD POP .126-.187G
4 21.9678.0767 1 EA ASSY, STABILIZER
4a - 10.9678.0757 1 EA STABILIZER, 1.377DIA
4b - 10.9678.0762 1 EA BRACKET, STABLIZER
4c - 53.6610.0003 1 EA SCREW, 6-32 X 7/16" PPZ
4d - 55.6568.0075 1 EA SPRING, EXTSN .375"OD 1.00"LG .041" WIRE DIA
5 21.9686.0800 1 EA ASSY, UPPER ENCLOSURE, VL3500 WASH
6 53.2019.0004 4 EA NUT, 3/8-16 X 7/32"THK HEX JAM GRD5 ZINC PLT
7 53.6505.0020 5 EA BOLT, 1/4-28X 3/4"HX HD GRD 8 ZINC PLT FULL THRD
8 53.6505.0026 4 EA BOLT, 3/8-16 X .500"LG H X HD GRADE 5 BLK 9/16"HEX HEAD X .23
TALL
9 53.6539.0001 4 EA WASHER, 3/8" SPLIT LOCK
10 53.5564.0250 1 EA SCREW, 6-32 X 1/4" PFB UNDERCUT
11 53.6624.0001 4 EA SCREW, 10-32 X 1/2"LG PFB
12 53.6513.0044 3 EA SCREW, M5 X 10MM STL CUP PT
13 54.1206.0014 2 EA RING, RETAINING 1.375"SHAFT 1.291"GRV DIA .056"GRVWD
EXTERNAL
14 54.1255.0001 2 EA BEARING ASSY, BLACK FLUSH MOUNT HOUSING
15 54.2055.0001 1 EA BELT, TIMING S2M 210GROOVE 9MMWIDE URETHANE/KEVLAR
16 55.6549.0001 5 EA WASHER, 1/4" SPLIT LOCK
17 55.6799.0001 2 EA SHIM, 1-3/8"ID, 1-7/8"OD, .010" THK, SS
18 55.6799.0002 2 EA SHIM, 1-3/8"ID, 1-7/8"OD, .005" THK, SS
19 25.9686.0204 1 EA CABLE ASSY, VARI-BRITE INTERCONNECT (
NOT SHOWN)
20 25.9686.0203 1 EA CABLE ASSY, TILT HARNESS (
NOT SHOWN)
21 10.9686.0629 1 EA PLUG, TILT TUBE
- 25.9686.0203 1 EA CABLE, TILT HARNESS (not shown)
- 25.9686.0204 1 EA CABLE ASSY, VARI-BRITE INTERCONNECT (not shown)
