VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
52 02.9686.0010 0
Top Assembly
VL3500 Wash Included Items Kit
28.9686.0001 Rev A
Refer to Figure 3-3.
No. Item Qty. UM. Description
1 02.8001.0001 1 EA SHEET, VARI-LITE CUSTOMER SERVICE
2 02.8052.0001 1 EA CARD, LIMITED WARRANTY (09-09-02)
3 02.8001.0002 1 EA
CERTIFICATE, VARI❋LITE QA
4 02.8700.0001 1 EA CARD, PRODUCT REGISTRATION
5 04.4037.0001 5 EA LABEL, 2.5 X .5 BARCODE (not shown)
6 08.3500.0002 1 EA CD-ROM, VL3500 WASH PRODUCT DOCUMENTATION
7 02.9686.0001 1 EA UNPACK/QUICK START SHEET, VL3500 WASH
8 22.9661.1636 2 EA FAB ASSY, BRACKET TRUSS HOOK
9 71.9686.1502 1 EA LAMP, 1500 WATT SHORT ARC, DOUBLE-ENDED (
IN LUMINAIRE)
10 21.9686.0620 1 EA INTERNAL LENS, FRESNEL
11 21.9686.0619 1 EA FRONT LENS ASSEMBLY, FRESNEL
12 21.9686.0618 1 EA FRONT LENS ASSEMBLY, CLEAR PC
