DRAWING TREES : VL3500™ WASH LUMINAIRE
02.9686.0010 0 51
3
VL3500™ Wash Luminaire (continued)
Figure 3-2: VL3500™ Wash Luminaire Subassembly Drawing Tree Part 2
Upper Enclosure Assembly
21.9686.0800
Internal Lens Assembly
21.9686.2150
Internal Lens Rail Assembly
21.9686.2140
Actuator Assembly
21.9686.2142
Internal Lens Splitter Assembly
21.9686.2144
Fresnel Internal Lenses
21.9686.0620
DMX Input PCB
24.9663.3895
Display PCB
24.9678.3825
Pan Pulley Assembly
21.9686.0807
Pan Motor Assembly
21.9686.0864
Pan Tube Assembly
21.9678.0881
Panel Assembly
21.9686.0805
1500W Arc Ballast Module Assembly
23.9686.1500
Ventilation Cover Assembly
21.9686.0840.02
EMI Filter to Power Switch Cable
Assembly
25.9678.0811
AC Input Pigtail Cable Assembly
25.9678.0810
Data I/O Link Cable Assembly
25.9678.0813
Display Cable Assembly
25.9678.1825
Ballast to Controller Cable Assembly
25.9678.0816
DC Output Cable Assembly
25.9678.0821
Pan/Tilt Control Cable Assembly
25.9678.0818
Lamp Supply to Relay Cable
Assembly
25.9678.0829
AC Input Splitter Cable Assembly
25.9678.0812
continued from previous page
continued from previous page
Chassis To Yoke Ground Cable
Assembly
25.9661.1520
LVS Chassis Ground Cable
Assembly
25.9661.1514
LVS Power Supply, 150W
69.3177.0151
LVS Chassis Ground Cable
Assembly
25.9661.1514
Exhaust Fan Assembly
21.9686.0811
LVS to Yoke Dual AC Fan Cable
Assembly
25.9686.0843
