Vari Lite VL3500 - Chassis To Yoke Ground Cable Assembly

CABLE ASSEMBLIES : CHASSIS TO YOKE GROUND CABLE ASSEMBLY
02.9686.0010 0 125
3
Chassis To Yoke Ground Cable Assembly
25.9661.1520 Rev C
Refer to Figure 3-50
Figure 3-50: Chassis To Yoke Ground Cable Assembly
No. Item Qty. UM. Description
1 52.8250.0006 2 EA TERM, #8, RING, 10AWG
2 73.7089.0504 15.17
FT
WIRE, 22AWG 300V 200C TEF GRN/YEL UL1180
1 (x2)
2
