02.9686.0010 0 49
CHAPTER 3.
Illustrated Parts Breakdown
This chapter contains illustrated parts breakdowns for the VL3500 Wash assemblies.
Note: The VL3500 Series Luminiares share many common assemblies and parts
of the Vari-Lite Series 3000 Luminaires.
• Drawing Trees
• Top Assembly
• Yoke Assembly
• Head/Yoke PCB Assemblies
• Enclosure Assembly
• Cable Assemblies
