VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
144 02.9686.0010 0
Chassis to Yoke Ground Cable Assembly
25.9661.1520 Rev C
Refer to Figure 3-69
Figure 3-69: Chassis to Yoke Ground Cable Assembly
No. Item Qty. UM. Description
1 52.8250.0006 2 EA TERM, RING #8, 10AWG
2 73.7089.0504 15.17 FT WIRE, 22AWG 300V 200C TEF GRN/YEL UL1180
1 (x2)
2
Yoke Ground Head Ground
