HEAD ASSEMBLY : INTERNAL LENS RAIL ASSEMBLY
02.9686.0010 0 75
3
Internal Lens Rail Assembly
21.9686.2140 Rev H
Refer to Figure 3-14
No. Item Qty. UM. Description
1 10.9678.0128 1 EA PULLEY, ZOOM MOTOR
2 10.9678.1131 1 EA FORWARD PULLEY SHAFT, BEARING
3 10.9686.1170 1 EA MOUNT, RAIL
4 10.9686.3171 1 EA MOUNTING PLATE, SPLIT LENS ZOOM ASSY
5 10.9686.1182 1 EA BLOCK, MOUNTING, IDLER PULLEY
6 55.2234.0001 1 EA E-RING, .188 SHAFT DIA.
7 22.9686.1154 1 EA LINEAR RAIL, 12MM, 2 LONG CARRIAGE
8 44.9663.1766 1 EA MOTOR, 17 1.24" SHAFT 11.8MH 5.5 OHM
9 53.2200.0006 1 EA NUT, 6-32 KEPS SS
10 53.6523.0001 5 EA SCREW, 6-32 X 3/8" SCB ALLEN
11 53.6543.0001 7 EA SCREW, 6-32 X 3/8" PPB
12 53.6614.0001 2 EA SCREW, 6-32 X 5/8" PPB
13 54.1262.0001 2 EA BEARING, FLANGED .1875 BORE
14 54.2064.0192 1 EA BELT, TIMING, MXL (.080), 192 GRV, 1/4" WIDE
15 54.2053.0001 1 EA MXT T BELT PULLEY, 20 GRV .25WD
16 10.9686.2130 1 EA END OF TRAVEL STOP
17 10.9686.1173 1 EA PAD, ISOLATION, ZOOM MOTOR
18 55.6568.0016 1 EA SPRING, EXTSN 0.125" OD, 0.500" LG
19 10.9621.0097 1 EA STABILIZER, STEPPER, GOBO WHEEL
20 53.6598.0312 1 EA SCREW, 4-40 X 5/16 PFB
