VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
124 02.9686.0010 0
LVS Chassis Ground Cable Assembly
25.9661.1514 Rev A
Refer to Figure 3-49
Figure 3-49: LVS Chassis Ground Cable Assembly
No. Item Qty. UM. Description
1 52.8231.0005 1 EA TERM, RING #6 BLUE 16-14 AWG REEL PIDG
2 52.8271.0001 1 EA FASTON RECEPT, 16-14 AWG (REEL)
3 73.3516.0504 3.5
IN
WIRE, 16 AWG 300V 105C PVC GRN/YEL UL1569
1
2
3
