Vari Lite VL3500 - VL3500 Wash Controller PCB Assembly

HEAD/YOKE PCB ASSEMBLIES : VL3500 WASH CONTROLLER PCB ASSEMBLY
02.9686.0010 0 103
3
VL3500 Wash Controller PCB Assembly
24.9686.0429 Rev B
Refer to Figure 3-35
Item UM. Description Ref.
10.9661.1275 1 EA HEATSINK, MAIN CONTROLLER
10.9678.0731 1 EA HEATSINK, CONTROLLER
10.9678.0746 1 EA GROMMET, PCB EDGE
10.9678.0885 1 EA KIT, THERMAL TRANSFER MAIN CONTROLLER
53.2200.0006 3 EA NUT, 6-32 KEPS SS
53.6616.0001 3 EA SCREW, 6-20 X 3/4"LG PPZ
53.6404.0003 2 EA SCREW, 4-40 X 1" PPZ
55.3303.0004 2 EA WASHER, #4 LOCK INT.TOOTH SS
55.6538.0002 3 EA WASHER, #6 NYLON NATURAL
55.2179.0001 1 EA CABLE ANCHOR MOUNT, #6 SCREW
