Vari Lite VL3500 - Internal Lens Replacement (Continued)

MAINTENANCE PROCEDURES : INTERNAL LENS REPLACEMENT (CONTINUED)
02.9686.0010 0 21
2
Internal Lens Replacement (continued)
Figure 2-3: Internal Lens Replacement
Detail A
Note:
Some components not shown for clarity.
CAUTION:
Clean any fingerprints on lenses with
isopropyl alcohol and a lint-free cloth.
* Head covers are attached by tethers.
Internal Lens Assembly
Retaining Knobs
Head Cover *
Retaining Knobs
Post
1/4-Turn Screw
Lens Assembly
Keyed Carrier
