VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
42 02.9686.0010 0
Power Supply (LVS) Replacement
VL Part No: 69.3177.0151
Repair Procedure
Step 1. Disconnect luminaire AC input cable from power source.
Step 2. As shown in Figure 2-15, at the enclosure, remove two 6-32 x 1/4" LG PPZ screws from the
display-side top cover and remove the cover.
Step 3. At power supply, disconnect wiring:
Step 4. Remove one 6-32 x 3/8" LG PPZ screw at the wiring end of the LVS.
Step 5. Loosen two 6-32 x 3/8" LG PPZ screws and slide the LVS towards upper enclosure fan to
remove it.
Step 6. Replace by performing steps 2 through 5 in reverse order.
Location Connector
N White AC Wires
L Black AC Wires
V + Red DC Wires
V - Black DC Wires
