VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
10 02.9686.0010 0
Testing
Luminaire Self-Tests
The luminaire is capable of running self tests by using the TEST menu functions. For detailed
instructions regarding the luminaire’s self-test function, refer to the VL3500™ Wash Luminaire
User’s Manual (02.9686.0001).
Calibration Sequence
The following is an outline of the luminaire’s standard calibration sequence:
Phase 1
• Tilt
•Strobe
• Color Wheel 1
• Color Wheel 2
Phase 2
•Dimmer
Phase 3
•Aperture
Phase 4
• VARI❋BRITE
•CTO
•Amber
•Magenta
Phase 5
•Pan
•Zoom
•Cyan
Auto Recalibration
Most mechanisms with sensors will check their sensor when at a zero position, if the sensor is not
detected within 3 seconds, the mechanism will recalibrate. This applies to all except pan and tilt, and
zoom. Pan and tilt are corrected continuously if required by encoders fitted to the motor shaft.
Note: Colors (CTO and CYM) only auto recalibrate when the dimmer has been closed for 3 seconds.
