Vari Lite VL3500 - Ventilation Cover Assembly

ENCLOSURE ASSEMBLY : VENTILATION COVER ASSEMBLY
02.9686.0010 0 111
3
Ventilation Cover Assembly
21.9686.0840.02 Rev B
Refer to Figure 3-39
No. Item Qty. UM. Description
1 10.9686.1249 4 EA POST, TRUSS HOOK
1a 10.9678.0850 4 EA POST, TRUSS HOOK, SHORT, EARLY PRODUCTION
1b 10.9678.0833 4 EA SPACER, 1.25 "
2 10.9686.0883 1 EA COVER, VENTILATION
3 10.9678.0837 1 EA AIR SEAL, FAN SIDE
4 10.9678.0838 1 EA AIR SEAL, APS SIDE
5 10.9678.0835 1 EA AIR SEAL, SHORT STRIP
6 10.9678.0836 1 EA AIR SEAL, LONG STRIP
7 10.9678.0887 2 EA RAIN COVER SOUND INSULATION, ALUMINUM COVER
8 53.6653.0027 4 EA SCREW, 1/4-20 X 1 5/8 SOC HEAD
9 54.1206.0015 4 EA RING, RETAINING, PRESS-ON, 1" SH
10 55.6549.0001 4 EA WASHER, 1/4" SPLIT LOCK
