VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
54 02.9686.0010 0
VL3500™ Wash Luminaire
20.9686.0001 Rev G
Refer to Figure 3-4
No. Item Qty. UM. Description
- 02.8405.0001 1 EA AC DANGER TAG, VL3500 (not shown)
- 04.9661.0033.01 1 EA LABEL, WARNING - 2000 SERIES (not shown)
- 04.9661.0039 1 EA LABEL, LINE CORD WARNING (not shown)
- 04.9686.0061 1 EA LABEL, AC INPUT RATING VL3500 WASH (not shown)
1 10.9686.0617 1 EA YOKE CROSSMEMBER, HEAT SHIELD
2 10.9686.0168 1 EA ZOOM MOUNTING BRACKET, LEFT
3 10.9686.0169 1 EA ZOOM MOUNTING BRACKET, RIGHT
4 10.9686.0732 2 EA COVER, YOKE THERMOFORM
5 21.9686.0010 1 EA ASSY, GENERIC LUMINAIRE
6 21.9686.0611 2 EA ASSY, HEAD COVER
7 21.9686.0660 1 EA ASSY, DUAL FAN TRAY DUCT
8 21.9686.2150 1 EA ASSY, SPLIT LENS
9 21.9686.0400 1 EA ASSY, COLOR/DIMMER/STROBE
10 24.9686.0429 1 EA PCB ASSY, VL3500 WASH CONTROLLER
- 21.9686.1121 1 EA CABLE ASSY, HEAD CABLE INTERCONNECT (not shown)
- 25.9686.0209 1 EA CABLE ASSY, TRANSFER FANS (not shown)
- 25.9686.0210 1 EA CABLE ASSY, UPPER ENCLOSURE FANS (not shown)
- 28.9686.0001 1 EA INCLUDED ITEMS KIT, VL3500 WASH (not shown)
11 53.6523.0013 8 EA SCREW, 6-32 X 3/8" PTB
12 53.6543.0001 10 EA SCREW, 6-32 X 3/8" PPB
13 53.6545.0007 10 EA SCREW, 8-32 X 3/8" LG PFB (not shown)
14 53.6558.0007 4 EA SCREW, 6-32 X 1/4" LG PPZ SEMS EXT ZINC PLT (not shown)
15 53.6558.0009 4 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
16 55.6677.0033 4 EA WASHER, .201" OD .125" ID .032" THK FLAT SS
