TOP ASSEMBLY : VL3500 WASH INCLUDED ITEMS KIT
02.9686.0010 0 53
3
Figure 3-3: VL3500 Wash Included Items Kit
Note: * = Do not handle lamp with bare hands. To keep the lamp glass as free from dirt and grease as
possible, wear clean cotton gloves.
6
7
2
4
8
(x2)
1
9*
3
1 Set of internal Fresnel Lenses
(Buxom lenses are installed in luminaire)
Fresnel and Clear PC Front Lens Assemblies
(Stippled PC lens is installed on luminaire.)
10
13
14
