Vari Lite VL3500 - Zoom Motor Cable Assembly

CABLE ASSEMBLIES : ZOOM MOTOR CABLE ASSEMBLY
02.9686.0010 0 145
3
Zoom Motor Cable Assembly
23.9686.0208 Rev 0
Refer to Figure 3-70
Figure 3-70: Zoom Motor Cable Assembly
No. Item Qty. UM. Description
1 25.9686.0207 1 EA CABLE ASSY, ZOOM MOTOR
2 24.9678.5916 1 EA PCB ASSY, ZOOM INTERCONNECT
1
2
