VARI❋LITE® - VL3500™ WASH LUMINAIRE SERVICE MANUAL
106 02.9686.0010 0
25 21.9686.0811 1 EA FAN ASSY, EXHAUST
26 23.9678.0687 1 EA ELEC ASSY, PAN EOT SENSOR
- 25.9661.1514 1 EA CABLE ASSY, LVS CHASSIS GROUND (not shown)
- 25.9661.1520 1 EA CABLE ASSY, CHASSIS TO YOKE GROUND (not shown)
- 25.9678.0811 1 EA CABLE ASSY, EMI FILTER TO POWER (not shown)
- 25.9678.0812 1 EA CABLE ASSY, AC INPUT SPLITTER (not shown)
- 25.9678.0813 1 EA CABLE ASSY, DATA I/O LINK (not shown)
- 25.9678.1825 1 EA CABLE ASSY, DISPLAY (not shown)
- 25.9678.0816 1 EA CABLE ASSY, BALLAST TO CONTROL (not shown)
- 25.9678.0821 1 EA CABLE ASSY, DC OUTPUT (not shown)
- 25.9678.0818 1 EA CABLE ASSY, PAN/TILT CONTROL (not shown)
- 25.9678.0829 1 EA CABLE ASSY, LAMP SUPPLY TO RELAY (not shown)
- 25.9686.0843 1 EA CABLE ASSY, DUAL AC FAN LVS TO YOKE (not shown)
27 53.2001.0003 1 EA NUT, 10-32 NYLON INSERT
28 53.2019.0004 4 EA NUT, 3/8-16 X 7/32" THK HEX
29 53.2200.0006 4 EA NUT, 6-32 KEPS SS
30 53.6505.0022 3 EA BOLT, 3/8-16 X 3/4"LG CARR
31 53.6515.0001 4 EA SCREW, 10-32 X 3/4" SCB CAP
32 53.6522.0001 1 EA SCREW, 6-32 X 1/4" PFZ
33 53.6522.0004 2 EA SCREW, 6-32 X 1/4" SOC HD
34 53.6525.0188 2 EA SCREW, 6-32 X 3/16" PPZ SEMS
35 53.6530.0023 2 EA RIVET, 1/8"OD POP .376-.500GRP
36 53.6539.0001 4 EA WASHER, 3/8" SPLIT LOCK
37 53.6545.0003 4 EA SCREW, 8-32 X 3/8" PFZ
38 53.6682.0022 4 EA SCREW, 8-32 X 3/8" LG PPZ SEMS
39 53.6556.0002 1 EA SCREW, 4-40 X 3/4"LG PPB
40 53.6558.0009 13 EA SCREW, 6-32 X 3/8"LG PPZ SEMS
41 53.6558.0010 11 EA SCREW, 6-32 X 1/4"LG PPZ BLACK
42 53.6558.0015 4 EA SCREW, 6-32 X 3/8" PPB SEMS EXT
43 53.6571.0003 1 EA SCREW, 6-32 X 1-1/2"LG PPB
44 53.6591.0001 2 EA SCREW, 6-32 X 1/4" PFZ
45 53.6609.0001 4 EA SCREW, 6-32 X 3/8" PFZ
46 53.6626.0001 1 EA SCREW, 10-32 X 1/2" PPZ
47 55.6575.0001 4 EA SCREW, 10-32 X 3/4" PPB
48 53.6634.1000 1 EA SCREW, 3/8-16 X 1.00" LG SOC
49 53.6653.0027 4 EA SCREW, 1/4-20 X 1 5/8"LG SOC
50 53.6513.0044 3 EA SCREW, M5 X 10MM STL CUP PT
51 54.1206.0014 2 EA RING, RETAINING
No. Item Qty. UM. Description
