ENCLOSURE ASSEMBLY : UPPER ENCLOSURE ASSEMBLY
02.9686.0010 0 107
3
52 54.1255.0001 1 EA BEARING ASSY, BLACK FLUSH MOU
53 54.2067.0001 1 EA BELT, TIMING S2M, 448 MM, 244 TEETH
54 55.2150.0003 2 EA STANDOFF, 1/4"HEX 6-32 1.125"L
55 55.2178.0001 3 EA CABLE ANCHOR MOUNT, #8 SCREW
56 55.2179.0001 3 EA CABLE ANCHOR MOUNT, #6 SCREW
57 55.2186.0001 5 EA CABLE TIE, .10"WD 4.00"LG SMALL (
NOT SHOWN)
58 55.2261.0001 1 EA SLEEVE, NYLON THIN WALL #6 SCR
59 55.2267.0001 2 FT RUBBER STRIP, SPONGE CLSD CELL
60 55.6503.0004 4 EA WASHER #8 FLAT
61 55.6532.0004 2 EA BRACKET, 6-32 THREADED HOLES
62 55.6543.0001 3.75 IN GROMMET STRIP, SERRATED .062"
63 55.6543.0002 1.54 FT GROMMET STRIP, SERRATED .125"
64 55.6549.0001 4 EA WASHER, 1/4" SPLIT LOCK
65 55.6658.0009 1 EA STANDOFF, 1/4" HEX 6-32 X 3/4"
66 55.6568.0074 2 EA SPRING, CPRSN .420"OD .750"LG
67 55.6577.0005 2 EA STANDOFF, 1/2" HEX 6-32 1.625"L
68 55.6580.0002 2 EA CABLE TIE, .18" WD X 8.0" LG (
NOT SHOWN)
69 55.6677.0044 1 EA WASHER, .877"OD.170"ID.093"THK
70 55.6699.0010 0.5 FT SLEEVING, 5/16" NON DIA WOVEN POLY ROUNDIT (
NOT SHOWN)
71 55.6775.0009 1 EA BUSHING, SNAP .750"ID 1"MT H
72 67.4018.0001 1 EA FERRITE, 26X28.5 X 13MM CYL
73 67.9686.1500 1 EA FILTER, EMI 1500W BALLAST
74 68.4541.0004 1 EA FERRITE, CLAMP ON, AXIAL (
NOT SHOWN)
75 68.9678.0827 1 EA CHOKE, COMMON MODE
76 69.3177.0151 1 EA LVS POWER SUPPLY, 150W +24V/6.3A
No. Item Qty. UM. Description
