1
2
3
4
5 (x4)
6 (x4)
7 (x4)
8 (x2)
Connector oriented on this side
9 (x2)
11 (x2)
10 (x6)
12
Note: Vari-Lite recommends
that this motor be replaced as a
complete assembly. Although
you can replace only the motor,
the pulley (Item 2) is bonded to
the motor shaft during
assembly and cannot be
removed intact. If you order a
replacement motor (Item 4),
also order the pulley (Item 2).
Contact Vari-Lite Customer
Service for installation
information.
