MAINTENANCE PROCEDURES : BALLAST ASSEMBLY REPLACEMENT
02.9686.0010 0 27
2
Figure 2-6: Ballast Assembly Replacement
Step 14. Follow Steps 2-13 in reverse order to install the replacement ballast. When reinstalling
ventilation cover, be sure standoffs are seated flush to chassis.
Top Cover
Ventilation Cover
Head not shown for clarity.
NOTE:
Left Side Cover
End Cover
Exhaust fan
Chassis ferrite (Do not remove)
Ballast Assembly (includes attached ferrite)
APS end bracket
To Next Page
