MAINTENANCE PROCEDURES : COLOR/DIMMER/STROBE ASSEMBLY REPLACEMENT
02.9686.0010 0 29
2
Figure 2-7: Color/Dimmer/Strobe Assembly Replacement
Color/Dimmer/Strobe Assembly
Top Head Cover
Screws
