Vari Lite VL3500 - Page 57

MAINTENANCE PROCEDURES : PAN ENCODER REPLACEMENT
02.9686.0010 0 39
2
Note: Make sure the encoder disk is centered in the optical sensor gap.
Figure 2-13: Pan Encoder Replacement
Ventilation Cover
Encoder
Pan Motor
Assembly
