Weber ALPHA COMPACT User Manual

Chapter 10 Troubleshooting Alpha Compact 32708612
Version: 14.12.2012 page 125 of 135
Product with creases in the Label
Fig. 10-2: Product with creases in the Label
Description:
The label has creases.
Instruction
Correct the labeler result as follows.
Step Procedure
1
Examine the application speed.
2
The pressure of the pusher roller is too low. Adjust height of the pusher roller.
3
*²Examine the setup of rotating shaft encoder.
Product with beveled Label
Fig. 10-3: Product with beveled Label
Description:
A label is beveled on the product.
Instruction
Please correct the labeler result as follows.
Step Procedure
1
Correct inclination of the labeler and the peeler blade.
*²Only if system is equipped accordingly.
