Chapter 6 Installation and Initial Operation Alpha Compact 32708612
Version: 14.12.2012 page 30 of 135
To avoid damaging the labeling during transport, do not overturn
the labeler, avoid strong vibrations, protect it from humidity and
rain. If it is supplied in cardboard boxes, please store at maximum
three systems on top of each other. If it is supplied in a wooden
box, do not put the wooden box on top of each other.
Remove the packaging material and the transport securing de-
vices only at the site of use, and transport the labeler in its original
packaging to the labeling site. If the labeler is not secured, it can
tip over easily when transported.
Requirements
The labeler is unpacked in delivery condition (differences are possible), e.g.:
It stands on a pallet
It is stretched in.
(only in case of protective cabinet) it is secured with additional straps
and resp. screwed together to the pallet with its rubber feet.
Required Resources
Suitable means of transport (fork lift or pallet truck with a payload of at least
600 kg)
When using a fork lift, drive slowly.
(Only with protective cabinet) For unloading the system from pallet, a double
hand fork lift truck or pallet jack or…
2 persons, who have to wear safety shoes.
Stable support for the labeler.
(Safety-) steel band scissors for removal of the straps.
Screw wrench for transportation safety device.
